Ethylene Absorber - EA

General Features

Semi-hermetic (piston) compressor
Air-cooled condenser
Open type unit design
Electrostatic powder coated galvanized steel outer cabinet
Delivered nitrogen-charged for leakage assurance
Indoor and outdoor units are delivered nitrogen-charged.
Evaporator:
- Copper pipe structure
- Aluminum fins
- Floor type or ceiling type option

Options

Hermetic (scroll or piston) compressor
Adiabatic pad outdoor unit condenser
Evaporator:
- Stainless steel tubular structure
- Epoxy or Blygold® coated fins
- Stainless steel cassette

Cold Series - CSO

Evaporation / Condensation Temperature -5/+40°C
Hermetic R404A

Condensing Unit Model	Q Watt	TP kW	C.O.P	Compressor Model	V m³	Power Supply
CSO/0140-HZ	1.573	0,80	1,96	MPT14RA-DANFOSS	01/14	220 V/1~/50 Hz
CSO/0205-HZ	2.430	1,02	2,38	DS22TB-DANFOSS	15/24	220 V/1~/50 Hz
CSO/0245-HZ	3.011	1,22	2,47	DS26TB-DANFOSS	25/30	220 V/1~/50 Hz
CSO/0325-HZ	3.946	1,66	2,38	DS34TB-DANFOSS	31/41	220 V/1~/50 Hz
CSO/0385-HZ	4.055	1,53	2,65	MTZ022-4-DANFOSS	42/46	380 V/3~/50 Hz
CSO/0500-HZ	5.222	2,04	2,56	MTZ028-4-DANFOSS	47/61	380 V/3~/50 Hz
CSO/0670-HZ	6.908	2,66	2,60	MTZ036-4-DANFOSS	62/93	380 V/3~/50 Hz
CSO/0740-HZ	8.048	2,86	2,81	MTZ044-4-DANFOSS	94/121	380 V/3~/50 Hz
CSO/0890-HZ	10.190	3,65	2,79	MTZ056-4-DANFOSS	122/138	380 V/3~/50 Hz
CSO/1065-HZ	12.050	4,40	2,74	MTZ064-4-DANFOSS	139/183	380 V/3~/50 Hz
CSO/1165-HZ	13.410	4,90	2,74	MTZ072-4-DANFOSS	184/208	380 V/3~/50 Hz
CSO/1250-HZ	15.390	5,83	2,64	MTZ080-4-DANFOSS	209/245	380 V/3~/50 Hz

Q		Refrigeration Capacity
TP		Nominal Compressor Input Power
C.O.P		Coefficient Of Performance
V		Room Volume

Frost Series - FSO

Evaporating / Condensing Temperature -25/+40°C
HERMETIC R404A

Condensing Unit Model	Q Watt	TP kW	C.O.P	Compressor Model	V m³	Power Supply
FSO/0145-HZ	1.690	1,13	1,49	MS34FB-DANFOSS	10/14	220 V/1~/50 Hz
FSO/0170-HZ	1.931	1,33	1,45	NTZ048-4B-DANFOSS	15/24	380 V/3~/50 Hz
FSO/0270-HZ	3.121	2,02	1,55	NTZ068-4B-DANFOSS	25/40	380 V/3~/50 Hz
FSO/0360-HZ	3.837	2,52	1,52	NTZ096-4B-DANFOSS	41/62	380 V/3~/50 Hz
FSO/0475-HZ	4.617	2,91	1,59	NTZ108-4B-DANFOSS	63/90	380 V/3~/50 Hz
FSO/0575-HZ	5.827	4,02	1,45	NTZ136-4B-DANFOSS	91/110	380 V/3~/50 Hz

Q		Refrigeration Capacity
TP		Nominal Compressor Input Power
C.O.P		Coefficient Of Performance
V		Room Volume
