General Features

CSP series split refrigeration groups for cold room applications;
The FSP series is designed for frozen room applications.

  • Hermetic (piston) compressor
  • Air-cooled condenser
  • User-friendly remote control panel
  • Galvanized steel cabinet with electrostatic powder coating
  • Delivered with 6 bar nitrogen charge for leakage assurance
  • Ready-to-install electrical panel with automatic control components
  • Evaporator:
    • Galvanized steel cabinet with electrostatic powder coating
    • Copper pipe
    • Aluminum fin

Options

  • Hermetic (scroll) compressor
  • Evaporator:
    • Stainless steel pipe
    • Epoxy or Blygold® coated fin
    • Stainless steel outer cabinet
Cold Series - CSP
Evaporating / Condensing Temperature -5 / +40°C
HERMETIC R404A
Condenser Unit Model

 Q
kW		 TP
kW		C.O.P Compressor Model

 V
m³		 Power Supply

 Evaporator Model

CSP/0140 HZ 1.59 0.72 2.23 AJ 4480 FZ TECUMSEH 01/14 230 V/1~/50 Hz PSEB 30.11.6
CSP/0205 HZ 2.56 1.04 2.47 AJ 4513 FZ TECUMSEH 15/24 230 V/1~/50 Hz PSEB 30.12.6
CSP/0245 HZ 2.77 1.18 2.34 AJ 4517P-FZ TECUMSEH 25/30 230 V/1~/50 Hz PSEB 30.21.6
CSP/0325 HZ 3.57 1.56 2.29 AJ 4519P-FZ TECUMSEH 31/41 230 V/1~/50 Hz PSEB 30.22.6
CSP/0385 HZ 4.28 1.64 2.62 FH 4524 XG TECUMSEH 42/46400 V/3~/50 Hz PSEB 30.22.6
CSP/0500 HZ 5.25 1.94 2.72 FH 4532 XG TECUMSEH 47/61400 V/3~/50 Hz PSEB 30.31.6
CSP/0670 HZ 6.74 2.50 2.70 FH 4538 XG TECUMSEH 62/93400 V/3~/50 Hz PSEB 30.32.6
CSP/0740 HZ 9.18 3.70 2.48 TAG 4553 Z / AG 4553P-TZ TECUMSEH 94/121400 V/3~/50 Hz PSEB 30.42.6
CSP/0890 HZ 10.26 4.15 2.47 AG4561P-TZ TECUMSEH 122/138400 V/3~/50 Hz PSEB 30.42.6
CSP/1065 Hz 11.93 4.57 2.61 TAG 4568 Z / AG 4568P-TZ TECUMSEH 139/183400 V/3~/50 Hz PSE 40.22.6
CSP/1165 Hz 12.86 5.20 2.47 AG 4573P-TZ TECUMSEH 184/208400 V/3~/50 Hz PSE 40.22.6
CSP/1250 Hz 14.18 5.57 2.55 AG 4581P-TZ TECUMSEH 209/245400 V/3~/50 Hz PSE 45.22.6
Q Cooling Capacity
TP Nominal Compressor Power kW
C.O.P. Coefficient of Performance
V Room Volume
Frost Series - FSP
Evaporating / Condensing Temperature -25°C / +40°C
Hermetic R404A
Condenser Unit Model
 Q
kW		 TP
kW		C.O.P. Compressor Model
 V
m³		 Power Supply
 Evaporator Model
FSP/0145 HZ 1.45 1.12 1.31 CAJ 2464 Z / AJ 2464P-FZ TECUMSEH 10/14 230 V/1~/50 Hz PSEB 30.12.6
FSP/0170 HZ 2.35 1.47 1.60 FH 2480 XG TECUMSEH 15/24400 V/3~/50 Hz PSEB 30.21.6
FSP/0270 HZ 3.30 2.13 1.55 FH2511 XG TECUMSEH 25/40400 V/3~/50 Hz PSEB 30.22.6
FSP/0360 HZ 4.09 2.56 1.60 TAG 2516 Z / AG 2516P-TZ TECUMSEH 41/62400 V/3~/50 Hz PSEB 30.32.6
FSP/0475 HZ 5.18 3.21 1.62 TAG 2522 Z / AG 2522P-TZ TECUMSEH 63/90400 V/3~/50 Hz PSEB 30.42.6
FSP/0575 HZ 5.66 3.84 1.47 TAG 2525 Z / AG 2525P-TZ TECUMSEH 91/110

400 V/3~/50 Hz

 PSE 40.21.8
Q Cooling Capacity
TP Nominal Compressor Power kW
C.O.P. Coefficient of Performance
V Room Volume
