Ethylene Absorber - EA

General Features Download Brochure

An ultrasonic humidifier is a humidification system that turns water into cold vapor with ultrasonic sound waves and spreads this vapor into the environment with a fan.

High moisture production capacity up to 9 L/hour
Droplet size less than 1 micron
Remote control panel and humidity sensor
Quiet operation
Automatic water level control system
Automatic washing system
High temperature protection and warning light
Low water protection and warning light
Overflow alarm

Capacity Table - NUH/NUH-ATM

Model 1	Model 2	Capacity	Room Volume	Power Consumption		Humidity Level	Power Supply
Model 1	Model 2	Capacity	Room Volume	NUH	NUH ATM	Humidity Level	Power Supply
NUH/3000	NUH-ATM/3000	2-3 lt/h	0 - 599 m³	140 Watt	340 Watt	%80-%98	230 V/1~/50-60 Hz
NUH/6000	NUH-ATM/6000	4-6 lt/h	600 - 899 m³	260 Watt	460 Watt	%80-%98	230 V/1~/50-60 Hz
NUH/9000	NUH-ATM/9000	6-9 lt/h	900 - 1199 m³	380 Watt	580 Watt	%80-%98	230 V/1~/50-60 Hz

Humidity Capacity Table Corresponding to Water Temperature - NUH/NUH ATM

Model 1	Model 2	10°C	20°C	30°C	40°C	50°C
NUH/3000	NUH-ATM/3000	2,0 lt/h	2,3 lt/h	2,5 lt/h	2,7 lt/h	3,0 lt/h
NUH/6000	NUH-ATM/6000	4,0 lt/h	4,5 lt/h	5,0 lt/h	5,5 lt/h	6,0 lt/h
NUH/9000	NUH-ATM/9000	6,0 lt/h	6,8 lt/h	7,4 lt/h	8,2 lt/h	9,0 lt/h

Ambient Conditions That The Unit Operating

Ambient Temperature	Supply Water Hardness (max)	Water Temperature	Water Supply Pressure	Power Supply
0/+35°C	8°(dH) German Hardness	0/+35°C	1-6 Bar	230 V/1~/50-60 Hz
